PP Film Properties: Applications in Flexible Packaging

1. Fundamental Properties and Classification of Polypropylene (PP) Films​

1.1 Core Characteristics of PP Films​

PP films are predominantly manufactured from polypropylene resin, utilizing processes such as extrusion, casting, or biaxial orientation. These films possess several key properties. Physically, they are lightweight, with a density of around 0.91g/cm³, and exhibit high transparency, often achieving a transmittance of over 90%. They also have moderate stiffness and remarkable fold resistance. Chemically, PP films demonstrate excellent resistance to acids, alkalis, oils, and most organic solvents, along with good weather resistance. However, they are susceptible to aging when exposed to ultraviolet light for extended periods. In terms of thermal properties, PP films have a melting point in the range of 165 – 170°C, offer good heat – sealability that may require specific processes or coatings, and can endure short – term exposure to 120°C. Their mechanical properties, including tensile and tear strength, vary significantly depending on the manufacturing process, and biaxial orientation can greatly enhance these characteristics.​

1.2 Main Types and Process Differences of PP Films​

Based on manufacturing methods and structural features, PP films can be classified into several types. Cast Polypropylene (CPP) films are produced by extruding molten resin through a T – die and directly casting it onto a cooling roll, with either uniaxial or no orientation. This process endows CPP films with excellent heat – sealability, high transparency, and a relatively low cost. With a typical thickness ranging from 20 – 100μm, they are well – suited for applications where these properties are crucial.​

Biaxially Oriented Polypropylene (BOPP) films undergo orientation in both the machine (MD) and transverse (TD) directions, aligning the molecular chains. As a result, BOPP films have a thickness usually between 12 – 50μm and exhibit high mechanical strength, good barrier properties against gases and moisture, and dimensional stability. Their tensile strength can reach three to five times that of CPP films, making them a preferred choice for applications demanding robust performance.​

Inflated Polypropylene (IPP) films are manufactured through blow molding, featuring low uniaxial or biaxial orientation. With a thickness of 10 – 100μm, IPP films stand out for their good flexibility, high impact resistance, and wide processing adaptability. These qualities make them suitable for various packaging applications where flexibility and resilience are required.​

Metallized BOPP (VMPP) films are created by depositing an aluminum layer onto BOPP films via vacuum metallization. The thin aluminum layer, typically 0.05 – 0.1μm thick, significantly enhances the film’s barrier against oxygen, moisture, and light, reducing oxygen permeability to less than 1cm³/day·m² and water vapor permeability to less than 1g/day·m². This makes VMPP films ideal for high – barrier packaging needs.​

Composite PP films are formed through dry lamination or extrusion lamination with other materials such as polyethylene (PE), polyethylene terephthalate (PET), or aluminum foil. This combination allows for the optimization of various properties, such as enhanced barrier and heat – sealability, to meet specific packaging requirements.​

2. Performance Comparison and Application Scenarios of Different PP Film Types​

2.1 Cast Polypropylene (CPP) Films: Balancing Cost and Heat – Sealability​

CPP films offer several advantages that make them popular in packaging. They have a wide heat – seal temperature range, typically between 140 – 180°C, which ensures high seal strength. Additionally, they exhibit good oil resistance, excellent transparency, and gloss, and are safe for food contact. However, they have limitations, including poor barrier properties against oxygen and moisture, as well as limited dimensional stability at high temperatures. To address these issues, lamination is often required.​

In flexible packaging, CPP films find extensive use. In the food industry, they are employed for snack bags, such as those for chips and cookies, frozen food pouches that need to withstand low temperatures, and retort pouches made from retort – grade CPP. In the consumer goods sector, they are used for stand – up or three – side – sealed bags for detergents and cosmetics, taking advantage of their heat – sealability and printability.​

2.2 Biaxially Oriented Polypropylene (BOPP) Films: High – Strength and Barrier – Driven Solutions​

BOPP films are characterized by their high strength and barrier properties. Their tensile strength is significantly higher than that of CPP films, and they have a low elongation at break of less than 100%. With good barrier properties, their oxygen permeability is around 50 – 100cm³/day·m², and they also offer superior printability, with a surface tension of at least 38 dynes. However, they lack heat – sealability and need to be laminated with CPP or PE, and they perform poorly at low temperatures, becoming brittle below – 10°C.​

These properties make BOPP films suitable for premium food packaging. They are used for twist – wrap films for candies and chocolates, thanks to their high transparency and gloss, and for moisture – proof bags for tea and coffee, often in combination with aluminum foil. In the labels and printing industry, BOPP films are utilized for self – adhesive labels and cigarette pack liners, especially when using BOPP matte or heat – shrink films, due to their stiffness and ability to provide clear prints.​

2.3 Inflated Polypropylene (IPP) Films: Prioritizing Flexibility and Processability​

IPP films excel in flexibility and processability. They have high impact resistance and excellent fold fatigue resistance, capable of withstanding over 100,000 folds without breaking. Compared to BOPP films, they offer better low – temperature flexibility and are more cost – effective. However, their transparency and gloss are slightly lower than those of CPP and BOPP films, and their mechanical strength is moderate.​

In flexible packaging, IPP films are used for flexible sacks, such as heavy – duty bags for flour and fertilizers that need to resist dropping, and garment storage bags that benefit from their fold resistance. In the agricultural sector, they are used for seed and pesticide bags, providing a balance between weather resistance and cost – effectiveness.​

2.4 Metallized PP (VMPP) Films: Enhanced Barrier Solutions​

VMPP films are designed for enhanced barrier performance. The aluminum layer on the BOPP film provides excellent light shielding, with a transmittance of less than 1%, and significantly improves the film’s barrier against oxygen and moisture. However, the aluminum layer is prone to scratching, necessitating lamination with PE or PET, and the heat – sealability of VMPP films depends on the laminated layer.​

In flexible packaging, VMPP films are used for high – barrier food packaging, such as vacuum bags for milk powder and coffee beans to prevent oxidation, and nitrogen – flushed bags for snacks. In the pharmaceutical industry, they are used for blister packs for tablets and capsules, often laminated with PVC or PE to block moisture and oxygen.​

2.5 Composite PP Films: Customized Performance Solutions​

Composite PP films are engineered to offer customized performance. Different combinations of materials result in unique properties. For example, the BOPP/CPP composite combines BOPP’s strength and CPP’s heat – sealability, making it suitable for three – side – sealed snack bags. The BOPP/VMPP/PE three – layer structure provides high – barrier protection, ideal for tea packaging to safeguard against oxygen and light. The CPP/Aluminum Foil/CPP composite is designed for retort pouches, capable of withstanding 121°C for 30 minutes, making it suitable for ready – to – eat foods.​

3. Technical Trends and Challenges of PP Films in Flexible Packaging​

3.1 Performance Optimization Directions​

The development of PP films focuses on several performance optimization directions. Lightweighting is a key area, where reducing the thickness of films, such as decreasing BOPP from 20μm to 15μm, aims to cut costs while maintaining strength. Functional coatings also play an important role. Applying silicon coatings can improve the slip properties of films, which is beneficial for high – speed packaging lines. Coatings of polyvinyl alcohol (PVA) or ethylene – vinyl alcohol copolymer (EVOH) can enhance the barrier performance of PP films. Additionally, efforts are being made to incorporate biodegradable materials like starch or polybutylene adipate terephthalate (PBAT) into PP films to develop fully bio – based products, although this technology is still in the research and development stage.​

3.2 Environmental and Sustainability Challenges​

PP films face environmental and sustainability challenges. Recycling is a major issue, especially for composite PP films with aluminum layers or multi – layer structures, which are difficult to recycle efficiently. This has led to a shift towards mono – material packaging, such as all – PP laminates, to improve recyclability. Moreover, plastic reduction policies, such as the EU Packaging Waste Directive that requires all packaging to be recyclable by 2030, are driving the development of more recyclable and degradable PP films.​

3.3 Innovative Application Cases​

Innovative applications of PP films are emerging. In the area of smart packaging, humidity – indicating coatings are being embedded in BOPP films for fresh produce like seafood and fruits, enabling real – time detection of spoilage. For microwave – safe packaging, specially treated CPP films that can resist 180°C microwave heating are being used for ready – to – eat food containers, providing convenience for consumers.​

4. Conclusion: PP Film Selection and Application Strategies​

When selecting PP films for flexible packaging, several factors need to be considered, including product requirements such as barrier needs, heat resistance, and cost, as well as process compatibility. For low – cost basic packaging, CPP or IPP films are ideal choices, especially for products with minimal barrier requirements, such as snacks and some consumer goods. When high – strength and good printing properties are required, BOPP films are preferred, suitable for labels, cigarette packs, and other premium printing applications. For high – barrier packaging of oxygen – and moisture – sensitive products like milk powder and pharmaceuticals, VMPP or composite structures are more appropriate. With the growing emphasis on environmental protection, attention should also be paid to recyclable mono – material PP films or degradable alternatives to meet regulatory requirements and market demands.​

As materials and processing technologies continue to advance, PP films will expand their applications in flexible packaging, evolving towards high – performance, lightweight, and sustainable solutions, meeting the diverse needs of the packaging industry.
